Philips Goldway G30E Bedside patient monitor

Category: Health Monitors

Clinicians need to respond swiftly to rapid changes in their patient’s condition. Having a highly reliable, versatile patient monitoring solution on hand saves precious time in determining the best course of care. Philips Goldway G30E is your choice for a cost-effective, easy to learn, pre-configured bedside monitor that provides reliable measurements (Philips ST/AR ECG and FAST-SpO₂).

Specifications

ECG

Lead type	3-lead or 5-lead selectable
Lead selection, 3-lead	I, II, III
Lead selection, 5-lead	I, II, III, aVR, aVL, aVF, V
HR measurement	Adult / pediatric: 15 bpm – 300 bpm Neonatal: 15 bpm – 300 bpm Step: 1 bpm
HR accuracy	±5 bpm or ±1 %, whichever is greater
Arrhythmia	21 calls
ST measurement range	-2.5 mV – +2.5 mV
Waveform speed	6.25 mm/s,12.5 mm/s, 25 mm/s, 50 mm/s
Gain selection	x 1/4, x 1/2, x 1, x 2, x 4, Auto
Pacemaker detection	Yes
Protection	Against electrosurgical interference and defibrillation

Non-invasive blood pressure (NBP)

Method	Automatic oscillometric
Parameters	SYS/DIA/MAP/Pulse Rate
Operating mode	Manual/Auto/STAT
Auto measure intervals	3, 5, 10, 15, 30, 60, 90, 120, 240, 480 minutes
Units	mmHg/kPa
Cuff pressure range, adult / pediatric	0 – 300 mmHg ( 0 kPa – 40.0 kPa)
Cuff pressure range, neonate	0 – 150 mmHg ( 0 kPa – 20.0 kPa)
Systolic measurement range, adult/ pediatric	30 mmHg – 254 mmHg (4.0 kPa – 33.9 kPa)
Systolic measurement range, neonate	30 mmHg – 135 mmHg (4.0 kPa – 18.0 kPa)
Diastolic measurement range, adult / pediatric	10 mmHg – 220 mmHg (1.3 kPa – 29.3 kPa)
Diastolic measurement range, neonate	10 mmHg – 110 mmHg (1.3 kPa – 14.7 kPa)
MAP measurement range, adult / pediatric	20 mmHg – 235 mmHg (2.7 kPa – 31.3 kPa)
MAP measurement range, neonate	20 mmHg – 125mmHg (2.7 kPa – 16.7kPa)
Accuracy, maximum standard deviation	8 mmHg (1.1 kPa)
Accuracy, mean error	±5 mmHg (±0.7 kPa)
Pulse rate range	40 bpm – 240 bpm
Pulse rate accuracy	±5bpm or ±5%, whichever is greater
